Product description：
Fast speed-25m/min forming speed ,very fast ,more efficiency.
Stable forming-the roller stand is vertical cast steel stand ,gearbox driving,very strong ,the forming very stable and final product very accurate.
High speed automatic metal roof sheeting trapezoidal roofing has many different shapes,usually different countries have its own popular design ,we can customize the machine as customers’ demand,High speed trapezoidal roof sheet is most popular in American market.
High speed automatic metal ibr roof sheeting trapezoidal roofing：
Working Flow as Below:
Uncoiling → Feeding material into machine →Roll forming → Auto cutting →Products receiving table
Characteristics:
1.Shape characteristics: The cross-section of the High speed automatic metal roof sheeting trapezoidal roofingis trapezoidal, which allows the steel plate to better disperse pressure when subjected to external forces, thereby improving its overall strength.
2.Application areas: The High speed automatic metal roof sheeting trapezoidal roofing are widely used in the construction and industrial fields. It is often used as a covering material for roofs and walls, and due to its lightweight and high-strength characteristics, it can effectively reduce the weight of buildings and improve their seismic performance.
The technical specifications of the High speed automatic metal roof sheeting trapezoidal roofing：
| Item | Name | Specifications |
| 1 | Raw material | PPGI,PPGL |
| 2 | Material thickness | 24/26 gauge （0.4-0.6 mm) |
| 3 | Machine frame | 350mm H beam structure |
| 4 | Material of rollers | High grade 45# forged steel,Chromed treatment |
| 5 | Roller stand | Vertical cast steel structure |
| 6 | Forming stations | 16 rows |
| 7 | Diameter of shafts | Φ80mm solid |
| 8 | Material of shafts | High grade 45#,with heat treatment |
| 9 | Forming speed | 25 m/min |
| 10 | voltage | 380V/50HZ/3P (as requested) |
| 11 | Transmission way | By gearbox |
| 12 | Main motor | 11 KW |
| 13 | Cutting blade material | Gcr12 quenched treatment |
| 14 | Cutting type | Hydraulic post cutting |
| 15 | Driving method | By pillar type Cylinder |
Hydraulic decolier：
Capacity:5 tons
Coil inner diameter:450-550mm
Feeding width: max 1220mm
Function:Supporting the coils and doing uncoiling,It adopts the hydraulic cylinder to make the decoiler expand and fit to the inner diameter of coils. It is equipped with the cantilever.Motor drive the coils running and can do forward and reverse running as well as do the decoiling with tension.
Feeding device：
1.Hand wheels on both sides can be used to adjust the feeding width.
2.Four stainless rollers can make the material go into the machine smoothly and prevent the scratch on the material surface.
3.There are three rows of orange plastic rollers can make the steel coil go into the machine smoothly.
Roll forming and transmission device：
1.rollers thick chromed good hardness for long service time.
2.Each roller has number and with keynotes, it can fix on the shaft stablely
3.gear and double chain,stable
Hydraulic cutting device：
We use four pillars cutting system structure, it can make sure the cutting stable.
PLC control system：
PLC brand:Delta(Taiwan) PLC, and transducer and touched screen
Encoder brand:Omron
Electrical components:Schneider
Operating language:English and Chinese(or as requested)
You can set the orders on this part,changing product length and quantity,it is really easy to operate,and there are aviation plugs to make it much easier to install the machine while it arrived.
Hydraulic station：
Hydraulic station motor:7.5KW
Hydraulic oil:46# hydraulic oil
Main components:Include a set of hydraulic tank, a set of hydraulic oil pump, two hydraulic pipes. And one of electromagnetism valve
